Two SSM2164 based linear VCAs in a small 6hp module. No signal bleed with zero volts CV. Features a true bypass switch and level pot for each channel. If only one CV is used, it copies to both channels. When both CV inputs are used, the CVs are independent.

TECHNICAL SPECS:

• 6 hp (30x128mm panel size)

• Depth: 39mm

• +12V 24mA

• -12V 20mA

• 5V 0mA
